TinyG Bot Mini CNC Mill

Image by rileyporter
Inspired by the "Mantis guys" I started this little cnc that is full laser cut-able. As always TinyG will drive the stepper motors and consume the gcode 🙂

The bot axis supports "face plates" Meaning, I have faces for NEMA 17 and NEMA 23’s. So you may pick your poison 🙂

Materials are 1/2 plywood (fine grain) and 1/4 masonite (hardboard)

Note: This is an weekend design and build session. I did not get as far as I hoped. Will attach captive nuts / motors most likely this week.

Ril3y

Laser Tag

Image by TunnelBug
