Extender Module
Image by Michael Kappel
Embedded Electronics Starter Kit from GHI Electronics
FEZ Spider Starter Kit
www.ghielectronics.com/catalog/product/297
FEZ Spider Starter Kit is the 1st commercially obtainable .NET Gadgeteer-compatible kit. it contains everything required for educators, hobbyists and even specialists. Embedded development is quick & effortless (FEZ) thanks to .NET Micro Framework, .NET Gadgeteer and the several GHI value added functions such as WiFi and USB Host.
The kit consists of:
FEZ Spider Mainboard
Show T35 Module (3.5" with touchscreen)
USB Client DP Module (with USB cable)
Camera Module
2x Multicolor LED Module (DaisyLink)
2x Button Module
Ethernet J11D Module
SD Card Module
USB Host Module
Extender Module
Joystick Module
10cm IDC cables (integrated with modules).
Assorted IDC Cable Pack:
4x 5cm IDC cables
3x 20cm IDC cables
1x 50cm IDC cable
Reusable Plastic Storage Box
FEZ Spider Mainboard is a .NET Gadgeteer-compatible mainboard primarily based on GHI Electronics’ EMX module. This tends to make FEZ Spider Mainboard the most feature-full .NET Gadgeteer compatible device in the industry. It contains all of .NET Micro Framework core attributes and adds numerous exclusive attributes, such as USB host, WiFi and RLP (loading native code). All these features combine to supply a fast prototyping platform.
Crucial Attributes:
14 .NET Gadgeteer compatible sockets that include these types: X, Y, A, C, D, E, F, H, I, K, O, P, S, T, U, R, G, B and Z.
Configurable on-board LED
Configuration switches.
Primarily based on GHI Electronics EMX module
72MHz 32-bit ARM7 processor
4.5 MB Flash
16 MB RAM
LCD controller
Complete TCP/IP Stack with SSL, HTTP, TCP, UDP, DHCP
Ethernet, WiFi driver and PPP ( GPRS/ 3G modems) and DPWS
USB host
USB Device with specialized libraries to emulate devices like thumb-drive, virtual COM (CDC), mouse, keyboard
76 GPIO Pin
two SPI (eight/16bit)
I2C
four UART
two CAN Channels
7 10-bit Analog Inputs
10-bit Analog Output (capable of WAV audio playback)
four-bit SD/MMC Memory card interface
six PWM
OneWire interface (accessible on any IO)
Constructed-in Real Time Clock (RTC) with the appropriate crystal
Processor register access
OutputCompare for producing waveforms with high accuracy
RLP allowing users to load native code (C/Assembly) for actual-time specifications
Extended double-precision math class
FAT File System
Cryptography (AES and XTEA)
Low energy and hibernate help
In-field update (from SD, network or other)
Dimensions: W two.25" x L 2.05" x H .5"
Energy
Low power and hibernate modes
Active power consumption 160 mA
Idle power consumption 120 mA
Hibernate power consumption 40 mA
Enviromental:
Demands .NET Gadgeteer normal red power modules.
RoHS compliant /Lead-free of charge compliant
Most EMX computer software functions are GHI exclusive, see computer software documentation for information.
For a lot more information about .NET Gadgeteer go to:
www.netmf.com/gadgeteer/
Photograph taken by Michael Kappel
www.MichaelKappel.com
